I. Core Design Highlights: Adjustable U-Shaped Platform

The key feature of this steel coil transfer cart is its flexibly adjustable U-shaped groove platform, which perfectly meets the customer’s need to transport coils of various specifications.

The U-shaped channel, made of high-strength steel, offers an adjustable width range of 800–1600 mm, accommodating steel coils with diameters from 800–2000 mm. The adjustment is manual and can be completed by a single operator in just 30 seconds, greatly enhancing operational flexibility.

The inner walls of the U-shaped channel are lined with anti-slip rubber pads, which increase friction between the coil and the platform. This provides multi-angle fixation, effectively preventing displacement or collision caused by starting, stopping, or turning during transport. It ensures both the surface integrity of the steel coils and safe, stable operation.

II. Core Technical Parameters of Steel Coil Transfer Cart: Ensuring Transport Reliability

Rated load capacity: 10 tons, meeting single-coil transport needs.

Power system: 48V high-capacity lead-acid battery, offering a range of ≥5 km and supporting over 8 hours of continuous operation — ideal for long-term, high-intensity material handling.

Mobility: Trackless design allows flexible navigation through narrow aisles in workshops and warehouses.

Platform height: 800 mm from the ground, facilitating easy loading/unloading with forklifts, cranes, and other handling equipment.

Safety features: Intelligent power display, overload protection, and emergency braking ensure comprehensive operational safety.

III. Cooperation Process and Customer Feedback

This project was facilitated by a professional intermediary in Shanghai, who coordinated every stage — from initial inquiry and technical confirmation to customized solution design, manufacturing, and final delivery and acceptance — ensuring efficient communication and smooth progress.

After the equipment was put into use, the customer reported:

“The adjustable U-shaped trough completely solved our challenge of transporting multi-specification steel coils. It’s easy to operate and provides stable transport. It not only reduces coil damage but also increases transfer efficiency by 40%. This equipment, recommended by the intermediary, perfectly meets our production needs. We plan to order three more units for our new workshop.”
