5-Ton Electric Rail Transfer Cart for Handling Steel Castings | PEISA 1–1000T Transfer Cart Manufacturer

A rail transfer cart is a heavy-duty material handling vehicle designed to operate on fixed rails. PEISA manufactures electric rail transfer carts with capacities ranging from 1 to 1,000 tons, which can be customized according to the load, transport route, and working conditions.

This 5-ton battery-powered rail transfer cart was designed for transporting steel castings inside the customer's factory. It travels along a fixed, straight rail route and is operated by wireless remote control, allowing the operator to control the cart from a safe position.

The battery-powered system provides approximately 4–5 km of travel range under suitable operating conditions, while the battery capacity can be customized according to the required travel distance and working schedule.

Why Choose a 5-Ton Battery-Powered Rail Transfer Cart?

The customer needed to move steel castings along a fixed and straight route inside the factory. The cart would not need to change direction frequently, and the operating frequency was relatively low.

Based on these working conditions, a rail transfer cart was selected instead of a trackless transfer cart.

For fixed transport routes, rail transfer carts can provide stable and repeatable movement. They also have a relatively simple structure and can be suitable for applications where the transport path does not need to change frequently.

The battery-powered design eliminates the need for a continuous power cable along the route, giving the cart greater flexibility while keeping the system relatively simple.

Detailed Specifications

• Load Capacity: 5 tons

• Cart Dimensions: 3000 × 2000 mm

• Platform Height: 500 mm

• Drive Motor: 2 × 1.0 kW

• Wheel Diameter: 300 mm

• Battery Capacity: 150 Ah

• Control Method: Wireless remote control + backup handheld pendant

• Travel Speed: 20 m/min

• Braking: Controller-based braking system

• Safety: Audible and visual warning lights

Designed for Steel Casting Handling

Steel castings can be heavy and difficult to move manually or with conventional material handling equipment. A rail transfer cart provides a stable platform for transporting castings between production areas, processing stations, storage areas, and other designated locations.

For this project, the fixed rail route made it possible to use a compact 5-ton cart with a straightforward configuration. The battery capacity, motor power, dimensions, and control system were selected according to the customer's actual operating requirements.

PEISA provides customized electric rail transfer carts from 1 to 1,000 tons. Depending on the application, we can customize the cart dimensions, power supply, battery capacity, rail gauge, travel speed, control method, and safety system.

If you are looking for a transfer cart for steel castings, molds, steel coils, machinery, or other heavy materials, send us your load weight, dimensions, transport route, and working conditions. We can recommend a suitable configuration for your application.

10t Rail Transfer Cart for Handling Steel

FAQ:

• How long can a battery rail transfer cart run on one charge? → 4–5 hours at full load, 48V-150ah Battery Powered.

• Is a 5-ton rail cart suitable for a small workshop? → deck 3m×2m, rail gauge customizable

• What is the difference between rail and trackless carts? → rail 2–3x cheaper, fixed route
