Self Propelled Trolley with Patterned Rubber Tires

Self-Propelled Trolley with Patterned Tires

This self-propelled trolley belongs to the DWP series. It is a battery-powered transport equipment. The battery is installed in the center of the trolley, providing power for the electrical control system and driving the motor to realize functions such as forward movement, backward movement, and turning. The biggest features of this equipment are its driving method and wheel design.

The drive adopts a differential drive system, which provides stronger power and smoother operation. At the same time, its rotation speed is relatively high, allowing the trolley to travel at a faster speed. This equipment can only be equipped with large-diameter patterned rubber wheels. The characteristics of these wheels are also very obvious: the large diameter allows the trolley to easily overcome small potholes and slopes, while the patterned rubber wheels provide stronger grip, reduce the possibility of slipping, and offer better stability.

update:7-30/2026

This is a custom-built 50-ton Self-Propelled Trolley. Its unique design features six solid, patterned rubber tires, providing enhanced stability during heavy transport. The customer's steel pipes are long and require frequent transport between different processing areas in the workshop, with varying routes. To ensure smoother transport, the Self-Propelled Trolley was equipped with large-diameter tires to better suit its practical transport needs.

It can change its route and direction at will, unrestricted by rails, making it ideal for use in complex workshops with complex aisles and changing transport routes.

Tire and Structural Design

To ensure stability and safety when transporting heavy loads, the Self Propelled Trolley features specially selected impact-resistant and wear-resistant industrial tires.

These tires offer a strong load-bearing capacity, supporting loads up to 50 tons while also ensuring smooth operation on concrete surfaces.

The trolley's body is constructed of thickened welded steel plates, providing high strength and resistance to deformation, ensuring long-term durability.
